The Speedmaster makes its inspiration and intentions clear from the start.

We took that laid back custom look and added a real big helping of attitude.

The result is a tough looking motorcycle with slash-cut pipes, blacked out engine casings and

black cast wheels with machined rims.

The Speedmaster celebrates the performance of its air-cooled 865cc parallel twin, 270º crank

engine in a unique 60’s hot rod style. A tank mounted tachometer, steel

braided brake lines, twin front discs and fl at bars confirm this motorcycle goes as well as it looks.

Make no mistake, whenever and wherever a Speedmaster arrives it leaves no one in any doubt as

to how great the ride has been on the way.

ENGINE AND TRANSMISSION:

Type Air-cooled, DOHC, parallel-twin, 270º firing interval

Capacity 865cc

Bore/Stroke 90 x 68mm

Fuel System Multipoint sequential electronic fuel injection with SAI

Final Drive X ring chain

Clutch Wet, multi-plate

Gearbox 5-speed

CHASSIS, RUNNING GEAR AND DISPLAYS:

Frame Tubular steel cradle

Swingarm Twin-sided, tubular steel

Wheels Front Cast aluminium alloy 5-spoke 18 x 2.5in

Rear Cast aluminium alloy 5 spoke 15 x 3.5in

Tires Front 110/80 R18

Rear 170/80 B15

Suspension Front Kayaba 41mm forks with polished stainless steel shrouds

and polished lowers, 130mm travel

Rear Kayaba chromed spring twin shocks with adjustable preload,

96mm rear wheel travel

Brakes Front Twin 310mm disc, Nissin 2-piston floating calipers

Rear Single 285mm disc, Nissin 2-piston floating caliper

Instrument display/functions Analogue speedometer and tachometer with odometer

and trip information

DIMENSIONS AND CAPACITIES:

Length 2420mm (95.3in)

Width (Handlebars) 830mm (32.7in)

Height 1160mm (45.7in)

Seat Height 720mm (28.3in)

Wheelbase 1655mm (65.2in)

Rake/Trail 33.3º/153mm

Dry Weight 229kg (504lbs)

Fuel Tank Capacity 19.3 liters (4.3 gal / 5.1 US gals)

PERFORMANCE: (MEASURED AT CRANKSHAFT TO DIN 70020)

Maximum Power 62PS / 61bhp / 46kW @ 6800rpm

Maximum Torque 74Nm / 55ft.lbf @ 3300rpm
